Raymarine E62354- e7 MFD User Manual

Wateringress
Wateringressdisclaimer
Althoughthewaterproofratingcapacityofthisproductmeets
theIPX6standard,waterintrusionandsubsequentequipment
failuremayoccuriftheproductissubjectedtocommercial
high-pressurewashing.Raymarinewillnotwarrantproducts
subjectedtohigh-pressurewashing.
Disclaimers
Thisproduct(includingtheelectroniccharts)isintendedtobe
usedonlyasanaidtonavigation.Itisdesignedtofacilitateuse
ofofcialgovernmentcharts,notreplacethem.Onlyofcial
governmentchartsandnoticestomarinerscontainallthe
currentinformationneededforsafenavigation,andthecaptain
isresponsiblefortheirprudentuse.Itistheuser’sresponsibility
touseofcialgovernmentcharts,noticestomariners,caution
andpropernavigationalskillwhenoperatingthisoranyother
Raymarineproduct.Thisproductsupportselectroniccharts
providedbythirdpartydatasupplierswhichmaybeembedded
orstoredonmemorycard.Useofsuchchartsissubjectto
thesupplier’sEnd-UserLicenceAgreementincludedinthe
documentationforthisproductorsuppliedwiththememorycard
(asapplicable).
Raymarinedoesnotwarrantthatthisproductiserror-freeorthat
itiscompatiblewithproductsmanufacturedbyanypersonor
entityotherthanRaymarine.
Thisproductusesdigitalchartdata,andelectronicinformation
fromtheGlobalPositioningSystem(GPS)whichmaycontain
errors.Raymarinedoesnotwarranttheaccuracyofsuch
informationandyouareadvisedthaterrorsinsuchinformation
maycausetheproducttomalfunction.Raymarineisnot
responsiblefordamagesorinjuriescausedbyyouruseor
inabilitytousetheproduct,bytheinteractionoftheproductwith
productsmanufacturedbyothers,orbyerrorsinchartdataor
informationutilizedbytheproductandsuppliedbythirdparties.
Chartcardsandmemorycards
Memorycardsareusedforarchivingdataandchartcards
provideadditionalorupgradedcharts.
Compatiblecards
Thefollowingtypesofmemoryorchartcardarecompatiblewith
yourRaymarineproduct:
•microSecureDigitalStandard-Capacity(microSDSC)
•microSecureDigitalHigh-Capacity(microSDHC)
Note:Themaximumcardcapacitysupportedis32GB.
Chartcards
Yourproductispre-loadedwithelectroniccharts(worldwide
basemap).Ifyouwishtousedifferentchartdata,youcaninsert
compatiblechartcardsintotheunit'scardslot.
Usebrandedchartcardsandmemorycards
Whenarchivingdata,Raymarinerecommendstheuseofquality
brandedmemorycards.Somebrandsofmemorycardmaynot
workinyourunit.Pleasecontactcustomersupportforalist
ofrecommendedcards.
EMCinstallationguidelines
Raymarineequipmentandaccessoriesconformtothe
appropriateElectromagneticCompatibility(EMC)regulations,
tominimizeelectromagneticinterferencebetweenequipment
andminimizetheeffectsuchinterferencecouldhaveonthe
performanceofyoursystem
CorrectinstallationisrequiredtoensurethatEMCperformance
isnotcompromised.
ForoptimumEMCperformancewerecommendthatwherever
possible:
•Raymarineequipmentandcablesconnectedtoitare:
–Atleast1m(3ft)fromanyequipmenttransmittingor
cablescarryingradiosignalse.g.VHFradios,cablesand
antennas.InthecaseofSSBradios,thedistanceshould
beincreasedto7ft(2m).
–Morethan2m(7ft)fromthepathofaradarbeam.A
radarbeamcannormallybeassumedtospread20degrees
aboveandbelowtheradiatingelement.
•Theproductissuppliedfromaseparatebatteryfromthatused
forenginestart.Thisisimportanttopreventerraticbehavior
anddatalosswhichcanoccuriftheenginestartdoesnot
haveaseparatebattery.
•Raymarinespeciedcablesareused.
•Cablesarenotcutorextended,unlessdoingsoisdetailedin
theinstallationmanual.
Note:Whereconstraintsontheinstallationprevent
anyoftheaboverecommendations,alwaysensurethe
maximumpossibleseparationbetweendifferentitemsof
electricalequipment,toprovidethebestconditionsforEMC
performancethroughouttheinstallation
RFexposure
ThistransmitterwithitsantennaisdesignedtocomplywithFCC
/ICRFexposurelimitsforgeneralpopulation/uncontrolled
exposure.TheWiFi/Bluetoothantennaismountedbehindthe
frontfaciaonthelefthandsideofthescreen.Itisrecommended
tomaintainasafedistanceofatleast1cmfromthelefthand
sideofthescreen.
FCC
ComplianceStatement(Part15.19)
ThisdevicecomplieswithPart15oftheFCCRules.Operation
issubjecttothefollowingtwoconditions:
1.Thisdevicemaynotcauseharmfulinterference.
2.Thisdevicemustacceptanyinterferencereceived,including
interferencethatmaycauseundesiredoperation.
FCCInterferenceStatement(Part
15.105(b))
Thisequipmenthasbeentestedandfoundtocomplywiththe
limitsforaClassBdigitaldevice,pursuanttoPart15oftheFCC
Rules.
Theselimitsaredesignedtoprovidereasonableprotection
againstharmfulinterferenceinaresidentialinstallation.This
equipmentgenerates,uses,andcanradiateradiofrequency
energyand,ifnotinstalledandusedinaccordancewith
theinstructions,maycauseharmfulinterferencetoradio
communications.However,thereisnoguaranteethat
interferencewillnotoccurinaparticularinstallation.Ifthis
equipmentdoescauseharmfulinterferencetoradioortelevision
reception,whichcanbedeterminedbyturningtheequipmentoff
andon,theuserisencouragedtotrytocorrecttheinterference
byoneofthefollowingmeasures:
1.Reorientorrelocatethereceivingantenna.
2.Increasetheseparationbetweentheequipmentand
receiver.
3.Connecttheequipmentintoanoutletonacircuitdifferent
fromthattowhichthereceiverisconnected.
4.Consultthedealeroranexperiencedradio/TVtechnician
forhelp.
10NewaSeries/NewcSeries/NeweSeries

Raymarine E62354- e7 MFD Specifications

General

Brand	Raymarine
Model	E62354- e7 MFD
Category	Marine GPS System
Language	English
