3.11e7/e7DPartssupplied
Thepartsshownbelowaresuppliedwiththee7/e7D
multifunctiondisplay.
D12170-3
x4
x4
x4
1
2
8
3
4
5
7
9
6
1.Suncover.
2.Frontbezel.
3.Multifunctiondisplay.
4.Rearbezel(requiredfortrunnionbracketmounting).
5.Gasket(requiredforushmounting).
6.Screwpack,includes:
•4xrearbezelxingscrews.
•4xsetsofxings(forsurfacemounting).
•4xsetsofxings(fortrunnionbracketmounting).
7.Documentationpack,includes:
•MultilingualCD.
•Mountingandgettingstartedmultilingualguide
•Mountingtemplate.
•Warrantypolicy
8.Poweranddatacable.
9.Trunnionbracketkit.
3.12NewcSeriesandNeweSeries
partssupplied
ThepartsshownbelowaresuppliedwiththeNewcSeriesand
NeweSeries(Excludinge7ande7D)multifunctiondisplays.
D12248-2
7
1
2
3
4
6
5
1.Suncover.
2.Frontbezel.
3.Multifunctiondisplay.
4.Gasket(requiredforsurfacemounting).
5.4xsetsofxings(forsurfacemounting).
6.Documentationpack,includes:
•MultilingualCD.
•Mountingandgettingstartedmultilingualguide
•Mountingtemplate.
•Warrantypolicy
7.Poweranddatacable.
34NewaSeries/NewcSeries/NeweSeries
