17.22Resettingthesonar

Theresetfunctionrestorestheunittoitsfactorydefaultvalues.

Note:Performingafactoryresetwillclearspeedand

temperaturecalibrationsettingsandthedepthoffset.

1.UsingacompatibleRaymarinemultifunctiondisplaygotothe

Fishnderapplicationpage.

2.SelectMenufromthesidemenu.

3.SelectSet-up.

4.SelectSounderSet-up.

5.SelectSonarreset.

6.SelectYestoconrm.

Theunitwillnowberesettofactorydefaultsettings.

Fishnderapplication

203
