RIGOL Chapter 6 Operations and Measurements
6-22 MSO4000/DS4000 User’s Guide
To Make One-key Measurement
MSO4000/DS4000 provides the one-key measurement function through which you
can measure the 29 kinds of waveform parameters as shown in the table below.
Please turn on the channel to be measured before making measurement.
Table 6-5 29 Waveform Parameters
Parameter Type Parameter Name
Time Parameter
Period, Freq, Rise Time, Fall Time, + Width, -Width,
+Duty, -Duty (please refer to “Time Parameters”)
Delay and Phase
Parameters
Dly A
→B , Dly A →B , Dly A →B , Dly A →B ,
Phs A
→B , Phs A →B , Phs A →B , Phs A →B
(please refer to “Delay and Phase Parameters”)
Voltage Parameter
Vmax, Vmin, Vpp, Vtop, Vbase, Vamp, Vavg, Vrms-N,
Vrms-1, Overshoot, Preshoot (please refer to “Voltage
Parameters”)
Area Parameter Area, Per.Area (please refer to “Area Parameters”)
You can perform one-key measurement following the steps below.
1. Specify the measurement source
The measurement source selection methods are different for different waveform
parameters.
Time, voltage and area parameter measurements
Press Measure Source, turn the multi-function knob to select the
channel to be measured and press the knob. You can also press Source
continuously to switch the current measurement source. The channels
available are CH1 to CH4, MATH and D0 to D15.
Note:
― When the current measurement source is CH1 to CH4 or MATH, you
can switch the measurement source by switching the current active
channel (press CH1 to CH4 or MATH at the front panel).
― When the current measurement source is D0 to D15, you can switch
