Chapter 11 Waveform Recording RIGOL
MSO4000/DS4000 User’s Guide 11-1
Chapter 11 Waveform Recording
The waveform recording function provides various recording modes (Record
Mode).
Record: record the channel waveforms at the specified interval until users stop the
recording operation manually or when the number of frames recorded reaches the
end frame currently set.
Open: record the channel waveform in real-time until users press RUN/STOP.
Playback: play back the waveform currently recorded.
Analyze: analyze the waveform currently recorded and provide the analysis results.
Note:
1. The waveform recording function is only available when the horizontal time base
mode is “Y-T”.
2. The digital channels (D0 to D15) only support waveform recording and playback
and do not support waveform analysis.
The contents of this chapter:
To Record Waveform Using the “Record” Mode
To Record Waveform Using the “Open” Mode
To Play Back the Waveform Recorded
To Analyze the Recorded Waveform
