Chapter 7 Logic Analyzer RIGOL
MSO4000/DS4000 User’s Guide 7-11
To Set the Delay Calibration of the Digital Channels
When using an oscilloscope for actual measurement, the transmission delay of the
probe cable may bring greater error (zero offset). Zero offset is defined as the offset
of the crossing point of the waveform and threshold level line relative to the trigger
position (refer to "To Set the Delay Calibration"). MSO4000/DS4000 allows users
to set a delay time to calibrate the zero offset of the corresponding channel.
Press LA ïƒ Delay-Cal and turn the multi-function knob to adjust the delay
calibration time at the specified step and the range available is from -100 ns to 100
ns. Pressing the multi-function knob
can quickly reset the delay time to 0.00 s.
Note: The delay calibration time setting is related to the instrument model and the
current horizontal time base. The larger the horizontal time base is, the larger the
setting step will be. Take MSO4054 as an example; when the horizontal time base is
50 ns, the step is 1 ns; when the horizontal time base is 2 μs, the step is 40 ns; when
the horizontal time base is greaten than or equal to 10 μs, the delay calibration time
cannot be adjusted.
