RIGOL Chapter 1 Quick Start
1-16 MSO4000/DS4000 User’s Guide
Front Panel Overview
Figure 1-12 Front Panel Overview
Table 1-1 Front Panel Description
No. Description No. Description
1 29 Parameters Measurement Menu
Softkeys
12 Record
2 LCD 13 Power Key
3 Multi-function Knob 14 USB HOST
4 Navigation Knob 15 Digital Channel Input Terminal
[1]
5 HORIZONTAL 16 Function Setting Menu Softkeys
6 CLEAR 17 VERTICAL
7 AUTO 18 Analog Channel Input Terminals
8 RUN/STOP 19 Function Keys
9 SINGLE 20 TRIGGER
10 Default and Print 21 EXT TRIG Input Terminal
11 LOGIC ANALYZER
[1]
22 Probe Compensation Signal Output
Terminal and Ground Terminal
Note
[1]
: Only applicable to MSO4000 mixed signal oscilloscope.
12
13 14 15 16 17 18 19 20 21 22
11
1 2 3 4 5 6 7 8 9 10
