RIGOL Chapter 7 Logic Analyzer
7-4 MSO4000/DS4000 User’s Guide
Note: For the waveform and label colors of the active channel(s) and other channels
currently turned on, please refer to “Digital Channel Waveform and Label
Colors”.
Auto Arrangement
Press LA and then press ReOrder to “D0-D15” or “D15-D0” (the default is
“D0-D15”).
D0-D15: D0 to D15 from top to bottom.
D15-D0: D15 to D0 from top to bottom.
To Perform Grouping Setting
You can group the 16 digital channels (4 user-defined channel groups: Group1 to
Group4) according to your need. Each user-defined channel group can include one or
more digital channels; but each channel can only be assigned to a single
user-defined channel group.
Press LA Group Set to enter the grouping setting menu. As the grouping
methods of Group1 to Group4 are the same, Group1 is taken as an example to
illustrate the grouping method.
In the grouping setting menu,
1. Select Group1
Press Group1 to select Group1. At this point, the channel list corresponding to
Group1 is opened. The selecting state label of each digital channel is dispalyed
at the left of the channel name.
denotes the channel can be selected;
denotes the channel cannot be selected (the channel is already assigned to
other user-defined channel group);
denotes the channel is already assigned
to Group1.
