RIGOL Chapter 2 Vertical System Setting
2-2 MSO4000/DS4000 User’s Guide
To Turn the Analog Channel On/Off
Connect a signal to the channel connector of CH1 and then press CH1 in the vertical
control area (VERTICAL) at the front panel to turn CH1 on or off. When it is turned on,
the backlight of CH1 is illuminated; the channel setting menu is displayed at the
right of the screen and the channel status label (as shown in the figure below) at the
bottom of the screen is highlighted.
Tips
The on/off of the backlights of the characters (“AC”, “50” and “BW”) under
CH1 and the information displayed in the channel status label are related to
the current channel setting. For the details, refer to “To Specify the
Channel Coupling”, “To Specify the Input Impedance” and “To
Specify the Bandwidth Limit”.
The on/off of the backlights of the characters (“AC”, “50” and “BW”) is only
related to the current channel setting; the on/off state of the channel has not
any effect on it.
After the channel is turned on, modify the parameters such as the vertical scale,
horizontal time base and trigger mode according to the input signal to make the
waveform displayed easy to observe and measure.
