Chapter 10 Pass/Fail Test RIGOL

MSO4000/DS4000 User’s Guide 10-5

Cursor Region Mode

In the cursor region mode, you can set the test mask range by adjusting the

positions of the cursors (cursor A and cursor B).

Press Utility  Pass/Fail  Range to open the mask range menu. In this menu,

1. Specify the test mask range to the cursor region

Press Range to switch to “Cursor”.

At this point, two gray cursor lines (used to indicate the current test mask range)

are displayed on the screen. Cursor A is on the left and cursor B is on the right.

2. Adjust the cursor positions (used to determine the test mask range)

 Press CursorA and turn the multi-function knob to adjust the

horizontal position of cursor A (namely adjust the left margin of the test

mask range).

 Press CursorB and turn the multi-function knob to adjust the

horizontal position of cursor B (namely adjust the right margin of the test

mask range).

 Press CursorAB and turn the multi-function knob to adjust the

horizontal positions of cursor A and cursor B at the same time (namely

adjust the left margin and right margin of the test mask range). At this point,

the horizontal distance between cursor A and cursor B remains unchanged.

Note:

 The horizontal distance between cursor A and cursor B should be at least 1

grid.

 When CursorA, CursorB or CursorAB is currently selected, pressing the

multi-function knob

continuously can quickly switch among the three.

3. Adjust the horizontal tolerance range

Press X Mask and turn the multi-function knob to adjust the horizontal

tolerance range of the test mask. The adjustable range is from 0.02 div to 4.00

div. During the adjustment, two white curves would be displayed in the interface

to show the outline of the current mask.
