Chapter 17 Specifications RIGOL
MSO4000/DS4000 User’s Guide 17-1
Chapter 17 Specifications
All the specifications are guaranteed except the parameters marked with “Typical”
and the oscilloscope needs to operate for more than 30 minutes under the specified
operation temperature.
Sample
Sample Mode Real-time sample
Real-time Sample
Rate
Analog channel:
4.0 GSa/s (interweave); 2.0 Gsa/s (non-interweave)
Digital channel: 1.0 Gsa/s
Peak Detect Analog channel:
250 ps (interweave); 500 ps (non-interweave)
Digital channel: 1 ns
Averaging After all the channels finish N samples at the same time, N
can be 2, 4, 8, 16, 32, 64, 128, 256, 512, 1024, 2048, 4096
or 8192
High Resolution when ≥5 μs/div @ 4 GSa/s (or ≥10 μs/div @ 2 GSa/s):
12 bit resolution
Minimum
Detectable Pulse
Width
Digital channel: 5 ns
Memory Depth Analog channel:
Auto, 14k pts, 140k pts, 1.4M pts, 14M pts and 140M pts
(interweave);
Auto, 7k pts, 70k pts, 700k pts, 7M pts and 70M pts
(non-interweave)
Digital channel: maximum 28M pts
