RIGOL Chapter 9 Reference Waveform

9-2 MSO4000/DS4000 User’s Guide

To Turn the Reference Waveform Channel On/Off

1. Enable the reference waveform function

Press REF in the vertical control area (VERTICAL) at the front panel to enable

the REF function and open the REF menu. The backlight of the key turns on

denoting that the reference waveform function is enabled. By default, only Ref1

channel is turned on.

Note: When the horizontal time base mode is X-Y, the reference waveform

function can not be enabled.

2. Turn the specified reference waveform channel on or off

In the REF menu, Press Channel and turn the multi-function knob to select

the specified reference waveform channel (Ref1 to Ref10); press the knob or

press Channel to turn the reference waveform channel on or off. When the

channel is turned on,

is displayed at the front of the reference waveform

channel name; when the channel is turned off,

is displayed.

Note: You can turn on a single reference waveform channel or multiple

reference waveform channels at the same time according to your need.

For the reference waveform channel that is turned on, the corresponding channel

icon (for example,

) is displayed at the left of the screen grid. You can also set the

reference waveform color, select the the reference waveform source channel, adjust

the vertical scale and vertical position of the reference waveform and save the

reference waveform to internal or external memory as well as recall it when needed.

For details, please refer to the introductions below.
