RIGOL Chapter 9 Reference Waveform
9-4 MSO4000/DS4000 User’s Guide
To Select the Reference Waveform Source Channel
1. Press REF  Current to select the specified reference waveform channel (Ref1
to Ref10) as the current reference waveform channel.
2. Press Source and turn the multi-function knob to specify a source (CH1 to
CH4, MATH or D0-D15) for the current reference waveform channel. You can
also press Source continuously to switch the source currently selected.
Note: Only channels (CH1 to CH4, MATH or D0-D15) that have been turned on
currently can be selected as the reference waveform source channel.
To Save and Display the Reference Waveform
1. Press REF  Current to select the specified reference waveform channel (Ref1
to Ref10) as the current reference waveform channel.
2. Press Save; the oscilloscope will save the waveform (screen region) of the
current reference waveform source channel to internal memory according to the
current setting and display it on the screen in the specified color and vertical
offset.
Note:
 This operation only saves the reference waveform in the volatile memory and
the waveform will be cleared at power-off.
 You can specify the reference waveform source channel by referring to “To
Select the Reference Waveform Source Channel”.
 You can specify the reference waveform color by referring to “To Set the
Reference Waveform Color”.
 You can adjust the vertical position and vertical scale of the reference waveform
by referring to “To Adjust the Reference Waveform Display”.
 After performing the “Save” operation, you can still set the reference waveform
color and adjust the display of the reference waveform (vertical position and
vertical scale).
