Chapter 13 Store and Recall RIGOL
MSO4000/DS4000 User’s Guide 13-3
Storage Type
Press Storage Storage to select the desired storage type. The descriptions of all
types are as follows. If no USB storage device is currently connected to the
instrument, only “Setups” is available.
1. Traces
You can save the waveform data in external memory in “*.trc” format. You can
recall the stored trace file (*.trc) when needed. The data from all the channels
turned on (analog channels and digital channels) can be saved in the same file.
At recall, the data will be displayed on the screen directly.
2. Waveforms
You can save the waveform data in external memory in “*.wfm” format. You can
recall the stored waveform file (*.wfm) when needed. The stored files contain
the waveform data of the four analog channels and the main setting information
of the oscilloscope and all the data can be recalled.
3. Setups
You can save the settings of the oscilloscope in internal or external memory in
“*.stp” format. You can recall the stored setup file (*.stp) when needed. At most
10 setting files (from LocalSetup0.stp to LocalSetup9.stp) can be stored in
internal memory.
4. Picture
You can save the screen image in external memory in “*.bmp”, “*.png”, “*.jpeg”
or “*.tiff” format. You can specify the filename and saving directory and save
the corresponding parameter file (*.txt) under the same directory using the
same filename. You can also set various information related to the image
storage. The recall of image and parameter files is not supported.
Tip
After a USB storage device is connected (no PictBridge printer is connected),
press
at the front panel to quickly save the current screen image under
the root directory of the USB storage device in the picture format currently
selected. When a PictBridge printer and USB storage device are connected at
the same time, the printer enjoys higher priority.
