Rockwell Automation Publication 2080-UM002L-EN-E - November 2021 153
Chapter 9 Controller Security
Configure Controller
Password
To set, change, and clear controller password, see the quickstart instructions
Configure Controller Password
on page 227.
Recover from a Lost
Password
If the controller is secured with a password and the password has been lost,
then it becomes impossible to access the controller using the Connected
Components Workbench software.
To recover, the controller must be set to Program Mode using the keyswitch for
Micro830, Micro850, and Micro870 controllers, the 2080-LCD for Micro810
controllers, or the 2080-REMLCD for Micro820 controllers. Then,
ControlFLASH™ can be used to update the controller firmware, which also
clears the controller memory. In Connected Components Workbench software
version 10 or later, the Reset option must be selected for the controller memory
to be cleared during the firmware update. If the Upgrade or Downgrade option
is selected, the password is retained.
Using the Memory Module
Plug-in
You can use the memory module to download a program into different
controllers. Make sure that the module is compatible with the Micro800
controllers. The 2080-MEMBAK-RTC2 module is compatible with Micro 830,
Micro850, and Micro870 controllers. The 2080-MEMBAK-RTC module is
compatible with Micro830 and Micro850 controllers.
Back up the project
To perform a project backup from a controller to the memory module, follow
these steps:
1. Create a new program and choose the desired controller.
The Micro850 controller is used for this example.
IMPORTANT
After creating or changing the controller password, you need to power down
the controller in order for the password to be saved.
ATTENTION: The project in the controller will be lost but a new project can be
downloaded.
