Rockwell Automation Publication 2080-UM002L-EN-E - November 2021 201
Appendix A Specifications
Certifications
Micro870 Controllers The following tables provide specifications, ratings, and certifications for the
Micro870 controllers. Catalog numbers with the suffix ‘K’ are conformal coated
and their specifications are the same as non-conformal coated catalogs.
Micro870 24-point Controllers
Certifications — Micro850 Controllers
Certification (when
product is marked)
(1)
(1) See the Product Certification link at rok.auto/certifications for Declaration of Conformity, Certificates, and other certification details.
Value
c-UL-us
UL Listed Industrial Control Equipment, certified for US and Canada.
See UL File E322657.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S. and
Canada. See UL File E334470.
CE
European Union 2014/30/EU EMC Directive, compliant with:
EN 61326-1; Meas./Control/Lab., Industrial Requirements
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
European Union 2014/35/EU LVD, compliant with:
EN 61131-2; Programmable Controllers (Clause 11)
European Union 2011/65/EU RoHS, compliant with:
EN 50581; Technical documentation
RCM
Australian Radiocommunications Act, compliant with:
EN 61000-6-4; Industrial Emissions
KC
Korean Registration of Broadcasting and Communications Equipment, compliant with:
Article 58-2 of Radio Waves Act, Clause 3.
EAC
Russian Customs Union TR CU 020/2011 EMC Technical Regulation
Russian Customs Union TR CU 004/2011 LV Technical Regulation
EtherNet/IP ODVA conformance tested to EtherNet/IP specifications.
General Specifications — Micro870 24-point Controllers
Attribute 2080-LC70-24AWB 2080-LC70-24QWB, 2080-LC70-24QWBK 2080-LC70-24QBB, 2080-LC70-24QBBK
Number of I/O 24 (14 inputs, 10 outputs)
Dimensions (HxWxD) 90 x 157 x 80 mm (3.54 x 6.18 x 3.15 in.)
Shipping weight, approx. 0.47 kg (1.04 lb)
Wire size
0.2…2.5 mm
2
(24…14 AWG) solid copper wire or
0.2…2.5 mm
2
(24…14 AWG) stranded copper wire
rated @ 90 °C (194 °F) insulation max
Wiring category
(1)
2 – on signal ports
2 – on power ports
2 – on communication ports
Wire type Use copper conductors only
Terminal screw torque
0.4…0.5 Nm (3.5…4.4 lb-in.) using a 0.6 x 3.5 mm flat-blade screwdriver.
Note: Use a handheld screwdriver to hold down the screws at the side.
Input circuit type
12/24V sink/source (standard)
24V sink/source (high-speed)
Output circuit type Relay
24V DC source
(standard and high-speed)
