Rockwell Automation Publication 2080-UM002L-EN-E - November 2021 189
Appendix A Specifications
For the Micro853 controller relay chart, see Relay Chart for Micro830,
Micro850, and Micro870 Controllers on page 206.
Micro830 24-point Controllers
Isolated AC Inputs — Micro830 16-point Controllers
Attribute 2080-LC30-16QWB, 2080-LC30-16QVB (Inputs 0…3)
On-state voltage, nom 12/24V AC @ 50/60 Hz
Off-state voltage, min 4V AC @ 50/60 Hz
Operating frequency, nom 50/60 Hz
Outputs — Micro830 16-point Controllers
Attribute
2080-LC30-16AWB, 2080-LC30-16QWB 2080-LC30-16QVB
Relay Output Hi-Speed Output (Outputs 0…1) Standard Output (Outputs 2…5)
Number of outputs 6 2 4
Output voltage, min 5V DC, 5V AC 10.8V DC 10V DC
Output voltage, max 125V DC, 265V AC 26.4V DC 26.4V DC
Load current, min 10 mA 10 mA 10 mA
Load current, max 2.0 A
100 mA (high-speed operation)
1.0 A @ 30 °C
0.3 A @ 65 °C (standard operation)
1.0 A @ 30 °C
0.3 A @ 65 °C (standard operation)
Surge current, per point
See Relay Contacts Ratings — Micro830 16-
point Controllers on page 189
4.0 A every 1 s @ 30 °C; every 2 s @ 65 °C
(1)
Current, per common, max 5 A — —
Turn on time/
Turn off time, max
10 ms 2.5 µs
ON: 0.1 ms
OFF: 1 ms
(1) Applies for general-purpose operation only. Does not apply for high-speed operation.
Relay Contacts Ratings — Micro830 16-point Controllers
Maximum Volts
Amperes
Amperes Continuous
Volt-Amperes
Make Break Make Break
120V AC 15 A 1.5 A
2.0 A 1800V A 180V A
240V AC 7.5 A 0.75 A
24V DC 1.0 A
1.0 A 28V A
125V DC 0.22 A
General Specifications — Micro830 24-point Controllers
Attribute 2080-LC30-24QWB 2080-LC30-24QVB 2080-LC30-24QBB
Number of I/O 24 (14 inputs, 10 outputs)
Dimensions (HxWxD) 90 x 150 x 80 mm (3.54 x 5.91 x 3.15 in.)
Shipping weight, approx. 0.423 kg (0.933 lb)
