Rockwell Automation Publication 2080-UM002L-EN-E - November 2021 253
Appendix D User Interrupts
STIS - Selectable Timed Start
STI0 is used in this document to define how STIS works.
The STIS instruction can be used to start and stop the STI function or to
change the time interval between STI user interrupts. The STI instruction has
two operands:
• IRQType — This is the STI ID that a user wants to drive.
• SetPoint — This is the amount of time (in milliseconds) which must
expire prior to executing the selectable timed user interrupt. A value of
zero disables the STI function. The time range is from 0…65,535
milliseconds.
The STIS instruction applies the specified set point to the STI function as
follows (STI0 is used here as an example):
• If a zero set point is specified, the STI is disabled and STI0.Enable is
cleared (0).
• If the STI is disabled (not timing) and a value greater than 0 is entered
into the set point, the STI starts timing to the new set point and
STI0.Enable is set (1).
• If the STI is currently timing and the set point is changed, the new
setting takes effect immediately, restarting from zero. The STI continues
to time until it reaches the new set point.
UID - User Interrupt Disable
The UID instruction is used to disable selected user interrupts. The table below
shows the types of interrupts with their corresponding disable bits:
Table 51 - STIS Parameters
Parameter Parameter Type
Data
Type
Parameter Description
Enable Input BOOL
Enable Function.
When Enable = TRUE, function is performed.
When Enable = FALSE, function is not performed.
IRQType Input UDINT
Use the STI defined DWORD
IRQ_STI0, IRQ_STI1, IRQ_STI2, IRQ_STI3
SetPoint Input UINT
The user timer interrupt interval time value in milliseconds.
When SetPoint = 0, STI is disabled.
When SetPoint = 1…65535, STI is enabled.
STIS or ENO Output BOOL Rung Status (same as Enable)
STISSTIS
STIS(name or Pin ID)
or ENO(Pin ID)
Enable
IRQType
SetPoint
UIDUID
UID (name or Pin ID)
or ENO(Pin ID)
Enable
IRQType
