Rockwell Automation Publication 2080-UM002L-EN-E - November 2021 187
Appendix A Specifications
For the Micro830 controller relay chart, see Relay Chart for Micro830,
Micro850, and Micro870 Controllers on page 206.
Micro830 16-point Controllers
Outputs — Micro830 10-point Controllers
Attribute
2080-LC30-10QWB 2080-LC30-10QVB
Relay Output
Hi-Speed Output
(Outputs 0…1)
Standard Output
(Outputs 2…3)
Output voltage, min 5V DC, 5V AC 10.8V DC 10V DC
Output voltage, max 125V DC, 265V AC 26.4V DC 26.4V DC
Load current, min 10 mA 10 mA
Load current, max 2.0 A
100 mA (high-speed operation)
1.0 A @ 30 °C
0.3 A @ 65 °C (standard operation)
1.0 A @ 30 °C
0.3 A @ 65 °C (standard operation)
Surge current, per point
See Relay Contacts Ratings — Micro830 10-
point Controllers on page 187
4.0 A every 1 s @ 30 °C; every 2 s @ 65 °C
(1)
Current, per common, max 5 A 2 A 4 A
Current, per controller, max 1440V A 2 A 4 A
Turn on time/
Turn off time, max
10 ms 2.5 µs
ON: 0.1 ms
OFF: 1.0 ms
(1) Applies for general-purpose operation only. Does not apply for high-speed operation.
Relay Contacts Ratings — Micro830 10-point Controllers
Maximum Volts
Amperes
Amperes Continuous
Volt-Amperes
Make Break Make Break
120V AC 15 A 1.5 A
2.0 A 1800V A 180V A
240V AC 7.5 A 0.75 A
24V DC 1.0 A
1.0 A 28V A
125V DC 0.22 A
General Specifications — Micro830 16-point Controllers
Attribute 2080-LC30-16AWB 2080-LC30-16QWB 2080-LC30-16QVB
Number of I/O 16 (10 inputs, 6 outputs)
Dimensions (HxWxD) 90 x 100 x 80 mm (3.54 x 3.94 x 3.15 in.)
Shipping weight, approx. 0.302 kg (0.666 lb)
Wire size
0.14…2.5 mm
2
(26…14 AWG) solid copper wire or
0.14…1.5 mm
2
(26…16 AWG) stranded copper wire
rated @ 90 °C (194 °F) insulation max
Wiring category
(1)
2 – on signal ports
2 – on power ports
Wire type Use Copper Conductors only
Terminal screw torque, max
0.6 Nm (4.4 lb-in.)
(using a 2.5 mm (0.10 in.) flat-blade screwdriver)
Input circuit type 120V AC
12/24V sink/source (standard)
24V sink/source (high-speed)
