Chapter 6 Program Execution in Micro800
user-defined variables, data memory also includes any constants and
temporary variables generated by the compiler at build time.
If your project is larger, it affects the power up time. Typical power up time is
10...15 seconds for all controllers. However, if your project has a lot of initial
and project values, it may cause the power up time to exceed 30 seconds. After
boot up, EtherNet/IP connections may take up to 60 seconds to establish.
The Micro800 controllers also have project memory, which stores a copy of the
entire downloaded project (including comments), as well as configuration
memory for storing plug-in setup information, and so on.
Guidelines and Limitations
for Advanced Users
Here are some guidelines and limitations to consider when programming a
Micro800 controller using Connected Components Workbench software:
• Each program/POU can use up to 64 Kb of internal address space. For
all
controllers exc
ept Micro870, it is recommended that you split larg
e
programs into smaller
programs to improve code readability, simpli
fy
debug
ging and maintenance tasks.
• A User Defined Function (UDF) uses significantly less
memory than a
User Defined Function Block (UDFB). For example, 30% less for a typical
sized
program compared to a UDFB
with one instance. The savings
in
creases as the number of UDFB instances increases.
• A User Defined Function Block (UDF
B) can be executed within another
UDFB, with a limit of
five nested UDFBs. Avoid creating UDFB
s with
references to
other UDFBs, as ex
ecuting these UDFBs too many times
may
result in a compile error. This also applies to UDFs.
Example of Five Nested UDFBs
• Structured Text (ST) is much more efficient and easier to use than
Ladder Logic, when used fo
r equations. If you are used to us
ing the
RSLogix 500® CPT Compute instruction, a great alternative is to use ST
combined with either UDF or UDFB.
As an example, for an Astronomical Clock Calculation, St
ructured Text
uses 40% less In
structions.
Display_Output LD:
Memory Usage (Code) : 3148 steps
Memory Usage (Data) : 3456 bytes
Display_Output ST:
Memory Usage (Code) : 1824 steps
Memory Usage (Data) : 3456 bytes
• You may encounter an Insufficient Reserved Memory error while
downloading and compiling a program over a certain size. One
workaround is to use arrays, especially if there are many variables.
UDFB1
UDFB2
UDFB3
UDFB4
UDFB5
