178 Rockwell Automation Publication 2080-UM002L-EN-E - November 2021
Chapter 10 Using microSD Cards
Use the Recipe Feature
Configure Recipe
1. In the Connected Components Workbench software, go to the Properties
pane to configure Recipe.
2. Select Recipe. Click Add Recipe to add a recipe. Note that each recipe will
be stored in separate files. You can add up to 10 recipes per
configuration.
3. Click Add Variable to add variables to the recipe. You can add up to 128
variables to each recipe.
For this quickstart sample project, add the following variables that you
have previously created to RCP 1:
Create Recipe Ladder Program
Configure Recipe
Build and Download
Execute RCP Function Block
Upload Recipe Files
Local Variables
Variable Name Data Type
data_bool BOOL
data_int8 INT
