Rotating the knob toward the right will increase the
volume of the multi-effects sound. Rotating the knob
toward the left will decrease the volume of the multi-
effects sound.
Making Multi-Effects Settings
The parameters of the effect will depend on the Multi
Effects Type that you selected. Of the parameters of
each effect, the main ones can be adjusted using the
front panel [MULTI CTRL 1/2] knob. For details on
which knob corresponds to each parameter, refer to
the explanatory diagram for each effect.
For example, in the case of the 4-band EQ, operation
will be as follows.
fig.7-17 (#MC fig.4-24)
In addition to setting them from the front panel, you can
also use the following procedure to set parameters except
Part Multi-Effects Switch while viewing their value.
1. Press [EDIT].
The indicator will light, and the edit page will appear
in the display.
2. Press BANK [2].
The effect setting page will appear.
3. Use PAGE [<] [>] to select parameters, and
use [INC] [DEC] or the [VALUE] dial to set
the value.
To exit the setting page, press [EXIT].
fig.7-18TEXT (#MC fig.4-25)
4 Band EQ (Modify the Tone)
This is a 4 band (high, midrange x 2, low) stereo equal-
izer.
fig.7-19 (#MC fig.4-28)
Low Freq (Low Frequency)
Determines the frequency of the low range.
Range: 200, 400 (Hz)
Low Gain [MULTI CTRL 2]
Adjusts the volume of the low frequency range.
Range: -15–+15
High Freq (High Frequency)
Determines the frequency of the high range.
Range: 4000, 8000 (Hz)
High Gain [MULTI CTRL 1]
Adjusts the volume of the high frequency range.
Range: -15–+15
Peak1 Freq (Peaking 1 Frequency)
Determines the frequency of midrange 1.
Range: 200–8000 (Hz)
