[ATTACK] (Attack Time)
The time from when the keyboard is pressed until the
maximum tonal change is reached.
Higher settings will cause the tonal change to occur
over a longer time.
[DECAY] (Decay Time)
The time from when the maximum tonal change is
reached until the Sustain Level is reached.
Higher settings will cause the tonal change to occur
over a longer time.
[SUSTAIN] (Sustain Level)
The cutoff frequency level at which the tonal change
will stabilize.
Raising this setting will also raise the cutoff frequency.
[RELEASE] (Release Time)
The time from when the keyboard is released until the
sound disappears.
Higher settings will cause the tonal change to occur
over a longer time.
Specifying the depth of the envelope
(Filter Envelope Depth)
This setting adjusts the depth of the filter envelope.
1. In the REALTIME MODIFY section, press [FIL-
TER/AMP/PITCH] several times to make the
FILTER indicator light.
2. Press [ENVELOPE/LFO1/EFFECTS] several
times to make the ENVELOPE indicator
light.
3. Use the [DEPTH] knob to adjust the Filter
Envelope Depth setting.
fig.6-19 (#MC fig.3-115)
Range: -63–+63
Rotating the knob toward the right of center will
increase the change in brightness. If the knob is rotat-
ed toward the left of center, the shape of the envelope
will be inverted, and the change in brightness will
become greater as the knob is rotated toward the left.
●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●
With both the FILTER and ENVELOPE indicators lit,
hold down [ENVELOPE/LFO1/EFFECTS], and use
[INC] [DEC] or the [VALUE] dial to set the Filter
Envelope Depth.
●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●●
Making More Detailed Settings
1. Press NUMBER [4] (FILTER).
The display will show the FILTER setting page.
2. Use PAGE [<] [>] to select parameters and
edit them.
fig.6-17 (#MC fig.3-113)
To Next Page
