152
Remote
Remote
Remote functions
You can use the rear panel MIDI IN/OUT connectors to remotely
control the M-480 from an external device, or control an external
device from the M-480. You can use either MIDI or RS-232C, not
both. If you want to use MIDI, set the rear panel RS-232C/MIDI
select switch to the MIDI position.
Always make sure to switch off the M-480’s power before
you change the setting of the MIDI/RS-232C select switch.
MIDI can transmit and receive the following messages:
If you connect a V-LINK compatible video device such as the V-
440HD to the rear panel MIDI IN connector, you’ll be able to use
your video device to control the volume of specific channels.
The M-480 allows up to sixteen audio sources to be controlled via
V-LINK.
The following V-LINK compatible video devices can be connected
to the M-480:
• V-440HD (Ver. 2.07 or later)
• V-44SW (Ver. 1.07 or later)
• V-8
• LVS-800
• V-1600HD
In order to use V-LINK, the MIDI/RS-232C select switch of the M-
480 must be set to the MIDI position.
The M-480 can use MIDI and USB MIDI simultaneously. If the
same message is received via both MIDI and USB MIDI, the last-
received message will be used.
By connecting the rear panel USB port to a PC, you can use USB
MIDI to remotely control the M-480.
USB MIDI can transmit and receive the following messages:
You’ll need to install the USB MIDI driver on the PC that’s to be
connected to the M-480 using USB. Download the USB MIDI
driver from the Roland website below:
http://www.rolandsystemsgroup.net/
The M-480 can be remotely controlled from M-480RCS via its
rear panel USB connector. M-480RCS is application software that
runs on Windows PC. It allows you to edit M-480 project files
and to remotely control the M-480. You can obtain the “M-
480RCS” software and the “M-480RCS Users Guide” (PDF
version) from the Roland website listed below. For details on
using M-480RCS, refer to the “M-480RCS Users Guide.”
http://www.rolandsystemsgroup.net/
You can use the RS-232C connector located on the rear panel to
control the M-480 from an external computer or other device. For
details on the RS-232C commands, refer to the “V-Mixer RS-232C
Reference” (PDF version), which you can obtain from the Roland
website listed below:
http://www.rolandsystemsgroup.net/
MIDI
Message
Explanation Transmitted/
Received
Control change
Control of channel faders and
mute
Transmitted/
Received
Program change Recall scene memories Transmitted/
Received
System exclusive Control of mixer parameters Transmitted/
Received
MMC Control of the USB memory
recorder
Received only
V-LINK
USB MIDI
Message
Explanation Transmitted/
Received
Control change
Control of channel faders and
mute
Transmitted/
Received
Program change Recall scene memories Transmitted/
Received
System exclusive Control of mixer parameters Transmitted/
Received
MMC Control of the USB memory
recorder
Received only
RS-232C
M-480_e.book 152 ページ ２０１１年３月２日 水曜日 午前９時２０分
