199
Appendix
Appendix
Display
800 x 480 dots Wide VGA backlit TFT color screen
Power Supply
AC 115 V, AC 117 V, AC 220 V, AC 230 V, AC 240 V (50/60 Hz)
Power Consumption
95 W
Dimensions
749 (W) x 614 (D) x 229.0 (H) mm
29-1/2(W) x 24-11/16(D) x 9-1/16(H) inches
Weight
20 kg
44 lbs 1 oz
Operation Temperature
+5 to +40 degrees Celsius
+41 to +104 degrees Fahrenheit
Accessories
Power Cord
REAC Connector Covers x 3
Ferrite Core x 4
Cover
Channel number sticker
Owner's Manual
Options (sold separately)
Cat5e Ethernet Crossover Cable with Neutrik(R) EtherCon(R) Plug: SC-W100S (100 m)
Cat5e Ethernet Crossover Cable with Neutrik(R) EtherCon(R) Plug and reel: W100S-R (100 m)
* 0 dBuÅÅ0.775 Vrms
* In the interest of product improvement, the specifications and/or appearance of this unit are subject to change without prior notice.
*1: When a REAC Splitter&Distributor S-4000D or a switching hub is used in-line with REAC cables, the network latency will increase by the amount of
processing delay introduced by the splitting device itself. The actual delay is dependant upon the specifications of the splitting device, though the
maximum delay amount for a single splitting device should be about 200 microseconds.
* In the interest of product improvement, the specifications and/or appearance of this unit are subject to change without prior notice.
