Input channel operations
Input channel operations
Most input channel operations can be performed in the CHANNEL EDIT section. Here we will explain input channel operations using the
CHANNEL EDIT section.
fig.ChEditSection.eps
Operations using the CHANNEL EDIT section
LAYER section
CHANNEL EDIT section
Fader module section
[SEL]
1.
In the LAYER section, press [CH 1–24] or [CH 25–48] to
assign the input channel to the fader module section.
2.
Press a [SEL] button to select the input channel that you
want to edit.
fig.ScrChDisp.eps
The CHANNEL DISPLAY screen will appear.
By default, RTN 1–6 are assigned to the fader 1–6 in USER Layer
3. The [SEL] button will toggle between the Left and Right of the
RTN channel each time you press it.
If you clear the check mark for the CHANNEL SELECT item
“CHANNEL DISPLAY follows CH SELECT button” in User
Preference (p. 141), pressing a [SEL] will select the channel
without showing the CHANNEL DISPLAY screen. In this case, you
can access the CHANNEL DISPLAY screen by pressing the [CH
DISP] in the CHANNEL EDIT section.
Selecting the channel
Even if you don’t access the CHANNEL DISPLAY screen, the
value of the currently-operated parameter is shown in the
sub display area when you operate any dial in the CHANNEL
EDIT section.
