54
Input channel operations
Input channel operations
5.
Press [F3 (PASTE)].
COPYCHConf1.eps
A confirmation message will appear, asking you to confirm
the Copy operation.
6.
Press [F8 (PASTE)] to execute the Copy.
Pressing [F7 (CANCEL)] will cancel the operation.
7.
Press [F8 (CLOSE)] to close the popup.
When you execute PASTE, the copy-destination channel select
buttons will be cleared.
You can recall channel settings from the library, or store the
settings of the current channel in the library.
Channel library operations are performed in the CHANNEL
LIBRARY popup.
1.
Access the CHANNEL DISPLAY screen for the desired
channel.
2.
Press [F4 (LIBRARY)] to access the CHANNEL LIBRARY
popup.
For details on library operations, refer to “Library operations” (p.
39).
fig.ScrChLibGuide.eps
Target channel
This indicates the channel that is the target of the CHANNEL
LIBRARY popup.
Library data list
This is a list of the library data.
Recall parameter select buttons
Use these to select the parameters that will be recalled.
You can select the following parameters:
Noise may occur when you execute a library preview or
recall, but this is not a malfunction.
The function buttons have the following operations:
Using the channel library
21 3
1
2
Phase
Phase
ATT Attenuator
HPF HPF (high-pass filter)
Gate Gate/expander
Comp Compressor
Delay Delay
EQ 4-band EQ
Fader Fader
Pan Pan
LCR LCR button, CENTER
AUX/MTX Send AUX/MTX sends
Direct Out Direct out point
To MAIN MAIN button, LR button, C button
[F2 (PREVIEW)] Previews (auditions) the selected library data.
[F3 (NAME EDIT)] Accesses the NAME EDIT popup.
[F4 (RECALL)] Recalls the selected library data.
[F5 (STORE)] Stores the current settings into the selected
library data.
[F6 (CLEAR)] Clears the selected library data.
[F7 (LOCK)] Locks/unlocks the selected library data.
[F8 (CLOSE)] Closes the popup.
3
