55
Input channel operations
Input channel operations
Input channels can be assigned to DCA groups and mute groups.
Assignments to DCA groups and mute groups are made in the
DCA/MUTE GROUP ASSIGN popup.
1.
Access the CHANNEL DISPLAY screen for the desired
channel.
fig.ScrChDisp.eps
2.
Press [F5 (DCA/Mute GROUP ASSIGN)] to access the DCA/
MUTE GROUP ASSIGN popup.
fig.ScrChGrpAsgnGuide.eps
Target channel
This indicates the channel that is the target of the DCA/
MUTE GROUP ASSIGN popup.
DCA GROUP select buttons
Use these to select the DCA group to which the channel will
be assigned.
MUTE GROUP select buttons
Use these to select the MUTE group to which the channel
will be assigned.
1.
Access the DCA/MUTE GROUP ASSIGN popup for the
desired channel.
fig.ScrChGroupAssign.eps
2.
Verify that the target channel is correct.
3.
Move the cursor to the desired DCA group select button,
and press [ENTER] to select it.
4.
Press [F8 (CLOSE)] to close the popup.
For details, refer to “DCA groups” (p. 112).
1.
Access the DCA/MUTE GROUP ASSIGN popup for the
desired channel.
fig.ScrChGroupAssign.eps
2.
Verify that the target channel is correct.
3.
Move the cursor to the desired MUTE group select
button, and press [ENTER] to select it.
4.
Press [F8 (CLOSE)] to close the popup.
For details, refer to “Mute groups” (p. 114).
Assigning channels to DCA
groups and MUTE groups
Accessing the DCA/MUTE GROUP ASSIGN
popup
2
1
3
1
2
3
Assigning a channel to a DCA group
Assigning a channel to a MUTE group
M-480_e.book 55 ページ ２０１１年３月２日 水曜日 午前９時２０分
