79
Dynamics
Dynamics
1.
Access the COMPRESSOR popup.
fig.PopComp.eps
2.
Press [F1 (OVERVIEW)] to access the COMPRESSOR
OVERVIEW popup.
fig.ScrCompOverview.eps
This shows the overall compressor status for CH1–48.
fig.ScrCompOverviewGuide2.eps
Channel number
ON button
This turns the compressor on/off.
Compressor graph
This shows the approximate response of the compressor.
GR (Gain Reduction) meter
This shows the amount of gain reduction for the compressor.
THR knob
This adjusts the threshold level of the compressor in a range
of -80.0 dB–0.0 dB.
The function buttons have the following operations:
You can recall compressor settings from the library, or store the
current compressor settings in the library.
The COMP LIBRARY popup is used to perform compressor library
operations.
1.
Access the COMPRESSOR popup.
2.
Press [F4 (LIBRARY)] to access the COMP LIBRARY popup.
fig.PopCompLibGuide.eps
Channel indication
This indicates the channel to which the GATE/EXPANDER
LIBRARY popup applies.
Library data list
This is a list of the library data.
The function buttons have the following operations:
For details on library operations, refer to “Library operations” (p.
39).
Listing the COMPRESSOR states
[F8 (CLOSE)]
Closes the popup.
1
2
3
5
4
1
2
3
4
5
Using the compressor library
[F2 (PREVIEW)]
Previews (auditions) the library data that is
selected in the list.
[F3 (NAME EDIT)] Accesses the NAME EDIT popup.
[F4 (RECALL)] Recalls the selected library data.
[F5 (STORE)] Stores the current settings into the selected
library data.
[F6 (CLEAR)] Clears the selected library data.
[F7 (LOCK)] Locks/unlocks the selected library data.
[F8 (CLOSE)] Closes the popup.
2
1
1
2
