140
7
Main
Specications
Locations of the Power Rating and Serial Number Labels
Serial number
This is required when you seek mainte-
nance, servicing, or support. Never peel
off the label.
Power ratings
Use an electrical outlet that meets the
requirements for voltage, frequency
, and
amperage given here.
141
143
