20
2
Basic
Operation
Loading Media
Loading Roll Media
CAUTION
Load roll media correctly.
Otherwise the media may fall and cause injury.
CAUTION
Roll media weighs about 40 kg (88 lb.). To avoid injury, handle the roll
media with care.
CAUTION
Never load roll media that weighs more than 40 kg (88 lb.).
The machine may tip over because it is incapable of withstanding the weight.
Alternatively, the media may fall out of the machine.
1.
Install the media on the media holders.
Note: The media holders of this machine are designed to be used exclusively with media that has a paper tube
(core) with an inner diameter of 3 inches. To use 2-inch media, the optional media anges are required. For
information about optional items, contact your authorized Roland DG Corp. dealer.
Open the front cover.
Loosen the retaining screws of the media holders, and then move them to the left
and right.
Secure the left media holder in the location shown in the gure.
Front cover
Left media holder
Grip
To Next Page
