71
3
Maintenance
Replacing Consumable Parts
Replacing the Wipers
The wipers are components that are used when cleaning the print heads. When the screen displays a mes-
sage like the one shown below, it is time to replace the items. There are two wipers. Replace both wipers with
new ones.
For information about purchasing wipers, contact your authorized Roland DG Corp. dealer.
CAUTION
Be sure to perform operations as specied by the instructions, and never
touch any area not specied in the instructions.
Sudden movement of the machine may cause injury.
1.
Enter the wiper replacement menu.
When the message shown in the gure appears, press
.
Remove any media.
Press .
Press several times to display the screen shown
on the left.
Press
.
Press several times to display the screen shown
on the left.
Press
.
Press .
The print-head carriage moves to a location where felt wiper replace-
ment is possible, and then the screen shown on the left appears.
Required items
MAINTENANCE
REPLACE WIPER
OPEN COVER R
Wipers Tweezers
To Next Page
