23
Button Operation and Displays
About the Display in the Upper Part of the Screen
You can check the following at any time in the upper part of the screen.
Checking the Selected Pad
The currently selected pad is continuously indicated in the upper part of
the screen.
Ex 1:
• Setting the snare (TRIGGER INPUT 3) pad head
fig.01-006
• Setting the snare (TRIGGER INPUT 3) pad rim
fig.01-007
Checking the Number of the Currently Selected Pattern or
Song and the Measure Number
Check here to determine whether a pattern or song is to begin playback
when [PLAY/STOP] is pressed.
• If a pattern number appears in the upper part of the screen, a pattern
will begin playback.
fig.02-001b
• If a song number appears in the upper part of the screen, a song will
begin playback.
fig.02-001c
For more detailed information about patterns and songs, refer to “Chapter
5 Playing Along with Patterns” (p. 96) and “Chapter 6 Playing Along with
Songs” (p. 120).
