Sega Double Spin User Manual

100
PARTS LIST
18
2 ASSY BILLBOARD (DB-0500UK) (D-1/1)
ITEM NO PART NUMBER DESCRIPTION QTY
***1 DB-0501UK BILLBOARD SURROUND 1
***2 DB-0502UK BILLBOARD COVER 1
***3 DB-0503UK BILLBOARD FRONT FACE 1
***4 DB-0504UK SPACER STANDOFF LONG 4
***5 DB-0505XUK BRKT MOUNT BILLBOARD 1
***6 280-6696UK 5.5-20X6.3 WSHR SPCL AL 4
***101 2
***102 DB-6002UK ASSY LED WHITE RGD 900MM 1
***201 030-000525 M5X25 BLT PAS 4
***202 068-552016 M5 WSHR 20OD FLT PAS 4
***203 060-S00500 M5 WSHR SPR PAS 4
***204 020-000510-0C M5X10 SKT CAP BZP 4
***205 020-000820-0Z M8X20 SKT CAP OZ 2
***206 068-852216-0B M8 WSHR 22OD FLT BLK 2
***207 060-S00800 M8 WSHR SPR PAS 2
1
2
3
4
5
102
204
205
201 202 203
206207

Sega Double Spin Specifications

General

Brand	Sega
Model	Double Spin
Category	Arcade Game Machines
Language	English
