LIGHTING TEST
Select LIGHTING TEST from the TEST MENU to display the LIGHTING TEST menu.
The LIGHTING TEST is used to test the functionality of the lights on the cabinet.
To implement the test, select a lighting test and press the Test button to turn on/off or cycle through the light(s).
ALL LEDS This will turn all lighting features for the cabinet on/off.
Pressing the TEST button will turn all LEDs on.
Press the SERVICE button to stop the test and return to LIGHTING TEST menu.
LED STEP DIRECT This will test the individual colours of the LEDs. Options available are
RED, GREEN, BLUE and WHITE.
Pressing the TEST button will cycle through the colours.
Press the SERVICE button to stop the test and return to the LIGHTING TEST menu.
LED STEP MUX This test will cycle through (in order) the LEDs on the top then bottom wheels. These lights are
used to illuminate the numbers of the wheels.
Pressing the TEST button will cycle clockwise around the top wheel followed by the bottom wheel.
Press the SERVICE button to stop the test and return to the LIGHTING TEST menu.
TEST MENU
2.LIGHTING TEST
LIGHTING TEST
ALL LEDS
ALL LEDS
ON
LIGHTING TEST
LED STEP DIRECT
LED STEP DIRECT
DIR:000 RED
LED STEP DIRECT
DIR:001 GREEN
LIGHTING TEST
LED STEP MUX
LED STEP MUX
MUX:000 WHITE
