Sega Double Spin User Manual

113
PARTS LIST
18
ITEM NO PART NUMBER DESCRIPTION QTY
**1 DB-0500UK ASSY BILLBOARD STD 1
**2 DB-1023UK DISC INNER UPPER LOW 1
**10 DB-0010UK SEGMENT SIDE L 1
**11 DB-0011UK SEGMENT SIDE R 1
**101 LM1227 UK MAINS LEAD 10A WITH PLUG 1
**102 LM1246 EUROLEAD 10A EUROPEAN SOCKET 1
**201 020-F00850-0Z M8X50 SKT CSK 0Z 1
**202 030-000816 M8X16 BLT PAS 2
**203 068-852216-0B M8 WSHR 22OD FLT BLK 2
**204 060-S00800 M8 WSHR SPR PAS 2
**205 020-000625-0C M6X25 SKT CAP CRM 6
**401 420-0017UK MANUAL DOUBLE SPIN 1
**402 OS1019 SELF SEAL BAG 9X12.3/4 1
**403 DOC-XXX DECLARATION OF CONFORMITY DB 1
**404 PK0489 BOX INST KIT DB STD 1
12 ASSY INST KIT (DB-INST-S) (D-1/1)
1
10
11
2
