TEST MENU
Press the TEST button to open the TEST MENU.
The following options are available from the TEST MENU.
SYSTEM INFO General Information and version numbers for software and hardware.
LIGHTING TEST Test functions for the lighting of the cabinet
DISPLAY TEST Test functions for the 7 segment LED and Starburst displays
INPUT TEST Test functions for switches, buttons, levers, ticket opto, and coin lines
OUTPUT TEST Test functions for ticket vend and coin and ticket meters
CALIBRATION Calibration functions for Lever Pull and Wheels
AUDIO SETTING Set volume levels for attract and in game audio
GAME SETTINGS Set Game mode, price of play, ticket value and percentage payout
BOOKKEEPING View game and ticket data and clear bookkeeping
SET DATE/TIME Set date and time
EXIT Exit the Test Menu to return to the game
Press the SERVICE button to move to the next Test menu option.
Press TEST button to enter the selected item.
The text TEST MODE will be displayed on LINE 1 of the 2x16 LCD screen. The current Test Function will be
displayed on LINE 2 of the screen. For Example:
SYSTEM INFORMATION
Select SYSTEM INFO from the TEST MENU to display the SYSTEM INFORMATION menu.
The SYSTEM INFORMATION test displays general information and version numbers for system hardware and
software.
Game Name and Version Info
Hardware and Serial Info
TEST MENU
1.SYSTEM INFO
TEST MENU
1.SYSTEM INFO
Double Shot
v0.1.0070
BOOTLOADER=v1.0
SERIAL#=0101fe04
