Sega Double Spin User Manual

109
PARTS LIST
18
8 ASSY DISC LOWER (DB-1300UK) (D-1/1)
ITEM NO PART NUMBER DESCRIPTION QTY
***1 DB-1201UK DISC CASE 1
***2 DB-1212UK COVER TANGENTIAL LED BD MKII 2
***101 838-0025UK PCBA-RGB SERIAL 24
***102 DB-6001UK ASSY LED WHITE RGD 40MM 16
***104 OS1249 P CLIP 6.5MM 10
***105 OS1195 RIVET SNAP MOSS SR1811 24
***201 012-P03506-F N6X1/4" S/TAP FLG PAS 20
***202 068-441616 M4 WSHR 16OD FLT PAS 10
***303 DB-60029UK WH WHEEL SEGMENTS 1
***305 DB-60031UK WH SERIAL PWR TOP 1
***306 DB-60033UK WH SERIAL LED LINK 18
***307 DB-60037UK WH SERIAL LINK PWR 1
***308 DB-60039UK WH SERIAL POWER LINK 5
1
2
101
201
202
102
