OUTPUT TEST
Select OUTPUT TEST from the TEST MENU to display the OUTPUT TEST menu.
This test is used to check all congured outputs from the IO board. This includes physical meters, ticket vends and
stepper motors.
METER OUTPUTS
This test will send a pulse to the game and ticket meters and increase their values by 1 unit. There is a test for each
meter, press the SERVICE button to select which meter to test and press the TEST button to initiate.
Select EXIT to return to the OUTPUT TEST menu.
TICKET OUTPUTS
This will test the ticket vend, use the SERVICE button to select either the left or right ticket vend and press TEST to
vend a single ticket.
A message will be displayed on completion of the test.
Select EXIT to return to the OUTPUT TEST menu.
MOTOR OUTPUTS
This will test the motors for the top and bottom wheels. There is a test for each wheel, press the SERVICE button to
select which wheel and press the TEST button to initiate.
After selecting the wheel to test the screen will display the message TOP SPINNING. During this test the TEST and
SERVICE buttons are disabled and you must wait for the test to complete before making another selection. It is not
possible to cancel the test.
Select EXIT to return to the OUTPUT TEST menu.
EXIT
Press the TEST button to exit OUTPUT TEST and return to the TEST MENU.
TEST MENU
5.OUTPUT TEST
METER OUTPUTS
TEST GAME METER
METER OUTPUTS
TEST TICKET METER
TICKET OUTPUTS
LEFT TKT VEND
TICKET OUTPUTS
VEND OK
MOTOR OUTPUTS
TEST TOP MOTOR
MOTOR OUTPUTS
TOP SPINNING
