Siemens simatic hmi op27 User Manual

10-5
OP27, OP37 Equipment Manual
Release 05/99
10.2 Force Tag
In addition to the functions provided by Status T ag operand values can be mod -
ified using the Force V ariable standard screen (
=
control).
The standard screen For ce V ariable is not integrated in the ProT ool standard
screens and must, therefore, be assigned to a function key .
Force Variable
MPI Operand Format Value
12 DB, DBB 100 10 BIN = 0000000000100000
1 ?????? 0 ????????? 0
1 ?????? 0 ????????? 0
1 ?????? 0 ????????? 0
1 ?????? 0 ????????? 0
1 ?????? 0 ????????? 0
1 ?????? 0 ????????? 0
1 ?????? 0 ????????? 0
1 ?????? 0 ????????? 0
1 ?????? 0 ????????? 0
Status:
Control Input
Back to main screen
123
ESC
Start/Stop update
Control input/start
123
Figure 10-4 Force Variable standard screen (example: OP37 with SIMATIC S7)
The structure of a line in the For ce V ariable standard screen corresponds to a
line in standard screen Status V ariable.
Function
Standard screen
Force V ariable
Status/Force T ag Using the OP
