18-14
OP27,
OP37 Equipment Manual
Release 05/99
18.3.2 Connection and Adjusting Elements
Each
of the two module boards has a 36-pin adapter for connecting the inputs/
outputs and the external voltage supply
.
When installed, the connectors are at the rear of the OP
.
0V +24V
Adapter
DO
DI
CPI 1 CPI 2
Figure 18-11 Location of connection elements on large module housing
(example: OP37)
Options
