Siemens simatic hmi op27 User Manual

1-1
OP27, OP37 Equipment Manual
Release 05/99
Product Description
The implementation of Operator Panels OP27 and OP37 enables operating
statuses, current process values and faults in respect of a connected PLC to be
graphically represented and the machine or system to be monitored easily oper -
ated. In order to do this, the OPs are equipped with a lar ge number of standard
functions. The method of display and operation of the OPs can be customized
using the ProT ool configuration software to achieve optimum results in respect
of process requirements.
The OPs can be used to
 control and monitor the process by means of the menu system. In this way ,
setpoints can be entered, for example, in the form of value input or pressing
configured function keys or to control positioning elements;
 display processes, machines and systems on full–graphic and semi–graphic
screens;
 visualize event messages, alarm messages and process variables, such as
output fields, bar graphs, trends or status display;
 intervene directly in the process by means of the integrated keyboard.
The OPs are installation units for use directly at the machine location. The
degree of protection is high (front panel IP65), so the devices are suitable for
use in hostile industrial environments.
Installation locations for the units may be as follows:
OP27 OP37
Panels/Consoles Panels/Consoles
– 19” panels/racks
Before commissioning the OPs, they must be prepared for the task of visualiz -
ing data from the PLC. T o do this, data areas must be created in the PLC’ s
memory in the configuration; the data areas are used by the OP to communi -
cate with the PLC.
Use of OP27 and
OP37
Installation
possibilities
Set up data areas
1
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Siemens simatic hmi op27 Specifications

General

Resolution	320 x 240 pixels
Power Supply	24 V DC
Operating Temperature	0 to 50 °C
Protection Class	IP65 (front), IP20 (back)
Display Type	LCD
Display Size	5.7 inches
Keypad	Yes
Backlight	Yes
Communication Ports	RS-232, RS-485
Communication Interface	MPI

Summary

Part I: Introduction

Product Description Overview

Details the features, installation possibilities, and configuration of the Operator Panels OP27 and OP37.

Functionality of Operator Panels

Provides an overview of the functions of OP27 and OP37, covering event/alarm messages, logging, and archives.

Part II: Functions

General Operation of Operator Panels

Describes the operating concept, screen partitioning, fixed and main areas, and icons for operator panels.

Password Protection and Access Levels

Details password levels, access permissions, and procedures for logging in, out, and managing passwords.

Handling Event, Alarm, and System Messages

Covers message types, display modes, archiving, deletion, and printing of messages on the operator panel.

System Settings Configuration

Describes how to configure general settings like operating mode, display, message logging, and date/time.

Part III: Installation and Commissioning

Mechanical Installation Procedures

Covers installation locations, conditions, degree of protection, and cautions for OP27 and OP37 mounting.

Electrical Installation Requirements

Details electrical connections, EMC compatibility, reverse battery protection, and power supply requirements.

Commissioning Process for Operator Panels

Explains the steps for initial startup, recommissioning, and normal operation of the OP27 and OP37.

Part IV: Equipment Description and Maintenance

OP27 Unit Description and Specifications

Details the dimensions, operating elements, connection elements, and communication options for the OP27.

OP37 Unit Description and Specifications

Details the dimensions, operating elements, connection elements, and communication options for the OP37.

Optional Units and Features

Describes optional components like AT expansion slots, Direct Key Modules, and Control Panel Interfaces.

Maintenance and Upkeep Procedures

Covers cleaning, battery replacement, and display/back-lighting maintenance for OP27 and OP37.

Part V: Appendix

Technical Data Specifications

Provides detailed technical specifications for OP27 and OP37 units, including housing, processor, memory, and power supply.

Interface Assignments and Pinouts

Details the pin assignments for IF1A, IF2, IF1B, IF3, and LPT interfaces on the operator panels.

Hardware Test Functions

Explains how to perform hardware tests, including internal memory, interfaces, keyboard, display, and functional units.

System Messages and Troubleshooting

Lists and explains system messages, their causes, and remedies for internal errors and operational issues.

SIMATIC HMI Documentation Overview

Provides an overview of the SIMATIC HMI documentation structure and target groups for various guides and manuals.

ESD (Electrostatic Sensitive Device) Guidelines

Provides safety guidelines for handling electronic components sensitive to electrostatic discharge.
