Page #90 background image
8-13
OP27,
OP37 Equipment Manual
Release 05/99
8.1.2 Transferring Data Records
The
following section describes how to operate the Selection Data Recor
d
Transmission
standard screen. This standard screen contains special functions
configured for transferring data records between the OP and PLC and between
the OP and data medium. As opposed to transfer using standard screen
Data
Recor
d Pr
ocessing
, intermediate steps are provided here for the transfer pro
-
cess. This means that it is possible to load a data record from the PLC in the
main memory of the OP
, edit the data record and then transfer the record back
to the PLC with modified values.
Proceed as follows to update the values in the data record in the OP main
memory with values from the PLC:
Step Action
1 Position the cursor in the Data Record Processing standard screen on the
symbolic input window Recipe.
Select the recipe for the data record to be updated from the selection win-
dow.
2 Select the name of the data record to be loaded in the OP (refer to Editing
a data record, Step 3, Page 8-10).
3
Press the function key assigned to the icon:
The data record is copied from the PLC in the main memory of the OP.
Proceed
as follows to transfer the current values in the main memory of the OP
to the PLC:
Step Action
1 Position the cursor in the Data Record Processing standard screen on the
symbolic input window Recipe.
Select a recipe for the data record to be transferred from the selection
window.
2 Select the name of the data record to be loaded in the PLC (refer to Edit-
ing a data record, Step 3, Page 8-10).
3
Press the function key assigned to the icon:
The data record is copied from the main memory of the OP to the PLC.
In this section
PLC
³
OP
OP
³
PLC
Recipes
