SIMATIC IPC647C
Operating Instructions, 12/2010, A5E02669337-02
135
Technical specifications
14
14.1 General specifications
General specifications
Order number 6AG4112-1...(for details, refer to the ordering documentation)
Dimensions 430.4 x 88.1 x 444.4 (W x H x D in mm). Detailed dimensional
specifications can be found in the
8Dimensional drawing of the
device (Page 3143) section.
Weight Min. 10 kg, max. 14 kg
Supply voltage (V
N
) 100 to 240 VAC (-15 %, 10 %), varying voltage; with transient
power failure backup in accordance with NAMUR:
Input current AC Continuous current up to 6 A (up to 30 A for 5 ms at startup)
Line voltage frequency 50 to 60 Hz (min. 47 Hz to max. 63 Hz, sinusoidal)
Transient voltage interruption Min. 20 ms at 93 V
(max. 10 events per hour; recovery time at least 1 s)
Power consumption Approx. 210 W maximum at 80% efficiency
Power loss / heat emission 210 W = 210 J/s = 0,20 BTU/s
Current delivery (DC) +5 V/30 A +3.3 V/28 A, max. accumulated power 160 W
+12 V/15 A -12 V/0.5 A -5 V/0.5 A +5 Vaux/2 A
Accumulated power of all voltages max. 170 W
Noise emission < 45 dB(A) at 25 °C to DIN EN ISO 7779
ODDs not in operation
Degree of protection IP41 at the front and IP20 at the rear to IEC 60529
Dust protection With closed front panel
Filter class G2 EN 779, 99% of particles > 0.5 mm are filtered
Safety
Protection class Protection class I according to IEC 61140
Safety regulations
IEC 60950-1
EN 60950-1
UL 60950-1
CSA C22.2 No 60950-1-07
Electromagnetic compatibility (EMC)
Radiated interference EN 61000-6-3, FCC class A
EN 61000-3-2 class D and EN 61000-3-3
Noise immunity: Mains borne
disturbance variables on supply lines
± 2 kV (to IEC 61000-4-4; Burst)
± 1 kV (to IEC 61000-4-5; Surge symm.)
± 2 kV (to IEC 61000-4-5; Surge asymm.)
Noise immunity on signal lines ± 1 kV (to IEC 61000-4-4; Burst; Length < 30 m)
± 2 kV (to IEC 61000-4-4; Burst; Length > 30 m)
± 2 kV (to IEC 61000-4-5; Length > 30 m)
Immunity to discharge of static
electricity
± 6 kV contact discharge (to IEC 61000-4-2)
± 8 kV air discharge (according to IEC 61000-4-2)
