Commissioning
7.2 Initial Commissioning - Initial Startup
SIMATIC IPC647C
40 Operating Instructions, 12/2010, A5E02669337-02
7.2 Initial Commissioning - Initial Startup
The Rack PC operating system is automatically set up the first time you switch on the
device. Procedure:
1. Press the on/off button behind the front panel door. The green power LED lights up. The
PC performs a POST. During the self-test, this message appears:
Press <F2> to enter SETUP
1. Wait until this message is cleared, then follow the instructions on the screen.
2. Type in the Product Key as required. You find this key on the "Certificate of
Authentication", in the "Product Key" line.
NOTICE
The PC may not be switched off when you run setup.
Do not change the default BIOS settings, otherwise the operating system setup may
become corrupted.
3. Automatic restart
After you have entered all necessary information and after the operating system
setup is completed, the PC is automatically restarted and displays the user interface of the
relevant operating system.
From now on, after you switch on the PC, the user interface of the operating system is
automatically opened when the startup routine is completed.
Switching off the device
Note
The device is equipped with a power supply unit with power switch.
Switch the line side switch to the "0" position. The device then consumes the lowest power
from the AC mains. It cannot be switched on using the on/off button at the front.
Note
On a Windows platform, always shut down the PC by clicking Start > Close.
Press the on/off button behind the front panel door. The green power LED is switched off.
WARNING
Completely separating the device from the power supply
For complete separation of the device from the power supply pull the power connector.
