16.1 Motherboard
16.1.1 Structure and functions of the motherboard
Core components of the motherboard: processor and chipset, three slots for memory
modules, internal and external interfaces, Flash BIOS and the backup battery.
2
4
1
3
Figure 16-1 Layout of the motherboard
①
Two memory module slots
③
Slot for the bus board
②
Processor without fan
④
Backup battery
