Detailed descriptions
16.7 CP 1616 onboard communications processor
SIMATIC IPC647C
Operating Instructions, 12/2010, A5E02669337-02
213
16.7.2.1 Loading firmware
Start downloading procedure
72. In the Windows Start menu, select the menu command SIMATIC > STEP 7 > NCM S7 >
Firmware Loader.
73. Click "Next" and follow the instructions in the dialog fields that follow. A help function is
integrated in the software as support.
CAUTION
Ensure that the loader file you are using for the update is suitable for the version of
firmware on your module. If you have any doubts, contact your local Siemens
consultant.
CAUTION
Be aware that aborting the loading process may result in an inconsistent state in your
module.
