Detailed descriptions
16.1 Motherboard
SIMATIC IPC647C
Operating Instructions, 12/2010, A5E02669337-02
151
Figure 16-2 Position of connectors
16.1.4 External interfaces
Interface Positio
n
Connecto
r
Description
COM1 Extern
al
X617 9-pin, standard connector
COM2 Extern
al
X615 9-pin, standard connector
LPT1 Extern
al
X609 25-pin, standard socket
PS/2 mouse Extern
al
X21
(7 to 12)
6-pin, miniature DIN socket (top socket)
PS/2 keyboard Extern
al
X21
(1 to 6)
6-pin, miniature DIN socket (bottom socket)
USB 2.0 Extern
al
X40A, B;
X41A, B;
X420
Port 0, 2; 4, 5; USB ports 1 and 3 at the front
PROFIBUS/MPI Extern
al
X600 9-pin, standard socket, electrically isolated interface
PROFINET Extern
al
RJ45
Ethernet 1 and 2 Extern
al
X40, 41 RJ45
DVI-I Extern
al
X302 Combined socket: 24-pin DVI-D plus 5-pin VGA
Microphone Extern
al
X60 (top) 6-pin 3.5-mm phono jack
Line out Extern
al
X60
(bottom)
6-pin 3.5-mm phono jack
