Detailed descriptions
16.5 BIOS Setup
SIMATIC IPC647C
Operating Instructions, 12/2010, A5E02669337-02
181
16.5.4 Main menu
Figure 16-4 Main menu (example)
Settings in the main menu
In the main menu, you can move up and down to select the following system configuration
boxes by means of the [↑] up and [↓] down cursor keys:
Field Meaning
System Time For viewing and setting the current time
System Date For viewing and setting the current date
System time and date
System Time and System Date indicate the current values. Once you have selected the
appropriate option, you can use the [+] and [-] keys to modify the time setting
Hour: Minute: Second
and for the date
Month/Day/Year
. You can navigate between the entries in the date and time fields (for example, from hour to
minute) using the ENTER key.
