Expansions and parameter assignment
10.4 Drive racks and storage media
SIMATIC IPC647C
Operating Instructions, 12/2010, A5E02669337-02
87
How to remove the Compact Flash card rack
5. Pull the plug from the CF
card rack (2).
1
2
The CF card rack is removed from the drive rack.
Installing the CF card rack
Perform the tasks describe above in reverse order.
10.4.6 Installation and removal of DVD drive
DVD drive
You can install and remove the DVD drive in the following drive racks:
● Vibration damped drive rack
● Drive rack for a removable rack
Preparations
11. Remove the drive rack from the device as described in the section .
12. Disconnect the connecting cable from the DVD drive.
